Aircraft systems manuals
Learn how aircrafts
work.
Click any part of the airframe to see how its systems operate, how they're maintained, and the checklists pilots use — referenced to the POH, FCOM and maintenance manuals.

Cessna 172S Skyhawk
Single-engine piston trainer
The most produced aircraft in history — the classroom of general aviation.
- Engine
- Lycoming IO-360-L2A, 180 HP
- Max takeoff weight
- 2,550 lb
- Cruise (75%)
- ~124 KTAS

Airbus A320ceo / neo
Narrow-body twin-jet airliner
The first fly-by-wire airliner with sidesticks — flight envelope protection as standard.
- Engines
- CFM56-5B / IAE V2500 (ceo); LEAP-1A / PW1100G (neo)
- MTOW
- 78,000 kg (ceo typical)
- Typical seats
- 150–180

Boeing 737-800 NG
Narrow-body twin-jet airliner
The best-selling jet family ever — conventional yokes and hydraulic flight controls.
- Engines
- CFM56-7B (NG) / LEAP-1B (MAX)
- MTOW
- 79,016 kg (-800)
- Typical seats
- 162–189

Airbus H145 (BK117 D-2)
Twin-engine light-utility helicopter
A bearingless four-blade rotor and a shrouded Fenestron tail rotor built for HEMS, police and utility work.
- Engines
- 2 x Safran Arriel 2E turboshafts, dual-channel FADEC
- MTOW
- approx. 3,700 kg (D-2) / 3,800 kg (D-3)
- Cruise speed
- approx. 135 kt

Lockheed Martin C-130J Super Hercules
Four-engine military/utility turboprop transport
A four-engine, high-wing tactical airlifter that can land on short, rough strips and drop cargo or paratroops from the air.
- Engines
- 4 x Rolls-Royce AE 2100D3 turboprops, approx. 4,590 shp each, FADEC
- Propellers
- 6-blade Dowty R391 composite scimitar, reversible pitch
- MTOW
- approx. 155,000 lb normal (175,000 lb max overload)
EDUCATIONAL USE ONLY. Content is summarised from manufacturer documentation for learning. It is not approved flight or maintenance data. Always use the current, aircraft-specific POH/AFM, FCOM, QRH, AMM and operator procedures.
